TES has the expert-level Computer Aided Design capabilities to cover every aspect of your project. Our mechanical designers and drafters have extensive industry expertise and advanced technical capabilities that can support the completion of your project. Over our 47 years, TES has provided CAD services to thousands of clients in a wide range of industries. As a result, we have developed the technical skill and management experience to provide design services for programs of any size. Our decades of experience, along with virtually all of the industry-leading Mechanical CAD applications and state-of-the-art hardware, ensures your project will be completed on time with superior quality.
Our Services
TES offers a full menu of CAD services. We can quickly respond to your needs by using our experienced team. Here are just a few of the many services we offer:
- Drafting
- 3D modeling
- Scanning services
- CAD file conversion
- CAD Re-mastering services (2D legacy to 3D solids)
- Platform translation
- Drawing Translation (Metric to Imperial)
TES professionals are highly proficient in the sophisticated software programs needed to complete your project effectively. To successfully deliver our services, we combine this expertise with a proven quality program. Most of our team has been with us for years and have thousands of hours of CAD experience, including all the latest software releases and the most up-to-date hardware. TES utilizes most mechanical CAD packages including:
- AutoCAD
- AutoCAD Electrical
- CATIA
- ProEngineer/CREO
- Inventor
- UG/Siemens NX
- Solid Edge
- Solid Works
And if you use something different, just let us know! We are always open to expand our software skills and service offerings to better serve our customers.
We specialize in these areas:
- Automotive
- Aerospace
- Automation Equipment
- Military/Defense Systems and Equipment
- Medical & Health Care
- Construction Equipment
Cost Savings
CAD services typically don’t require a senior engineering professional. Depending on the complexity the work can be completed by someone with one to five years experience. This enables TES to provide its clients with very attractive bill rates, many times, lower than its clients' internal burden rates.
Solid/3D Modeling
TES’s team of CAD technicians can quickly convert 2D drawings into 3D parametric models utilizing a variety of CAD platforms. The use of solid modeling technology is essential when doing Computer-Aided Engineering (CAE).
File Conversion
With multiple CAD systems in use today and the on-going need to share information, CAD file conversion has become a necessity. Since no two CAD systems are completely compatible, the source and conversion formats must be carefully considered. TES can perform translations between common CAD formats (including DXF, IGES, and STEP).
